Generator Power Converter Performance Characteristics And Specifications
The on grid generator power converter adopts AC-DC-AC PWM rectification plus PWM full-bridge inverter two-stage circuit technology. The core control adopts dual DSP full digital control, and realizes the stator magnetic field oriented vector control strategy on the rotor side converter of power generation. The grid-side converter implements the grid voltage directional vector control strategy; the system has the functions of adjustable input and output power factor, automatic soft grid connection and maximum power point tracking control. The power module uses high switching frequency IGBT power devices to ensure a good output waveform. This rectifier inverter device has the advantages of simple structure and less harmonic content.
LCD Operation And Display Instructions
Operation Main Interface
The factory setting: internal parameters have been proofread before delivery, please don't change settings without permission, otherwise it may destroy the inverter.
Inverter Output Display Interface
Generator Parameter Display Interface
Parameter Setting Interface
Specification
We have our own factory, provide customized generator according to each customer 's requirements of Voltage, Speed, Power, Frequency etc.
Why Choose Us
Frequently Asked Questions
What core technology does the generator power converter use?
The converter adopts AC-DC-AC PWM rectification plus PWM full-bridge inverter two-stage circuit technology. The core control is powered by dual DSP full digital control, implementing advanced vector control strategies for optimal performance.
Are the input and output power factors adjustable?
Yes, the system is designed with adjustable input and output power factors, and features automatic soft grid connection alongside maximum power point tracking (MPPT) control.
Can I customize the specifications for the generators?
Absolutely. We offer customized generator solutions manufactured in our own factory tailored specifically to client requirements for Voltage, Speed, Power, Frequency, and other key technical parameters.
Should I modify the internal parameters on the LCD screen?
No, all internal parameters are fully proofread and set at the factory prior to delivery. Changing these settings without authorization is highly discouraged as it may cause damage to the inverter.
What components ensure a clean output waveform?
The power module utilizes high switching frequency IGBT power devices. This configuration ensures a high-quality output waveform with minimal harmonic content and a simplified overall system structure.
What operational interfaces are viewable on the LCD display?
The LCD panel provides direct access to several monitoring screens, including the Operation Main Interface, Inverter Output Display Interface, Generator Parameter Display Interface, and the Parameter Setting Interface.
