Solar power is the generation effect of a solar panel pack that converts solar energy into direct current energy and stores it in a battery. Solar power supply system consists of solar panel, solar charge controller, battery, inverter, AC load, etc. A solar panels converts solar energy into electricity in the presence of light while charging the battery; in the absence of light, the battery supplies power to the load.
The solar charging controller adopts the step-by-step current-limiting charging method and automatically controls the turn-on or cut-off of the multi-channel solar panels according to the change trend of voltage at the battery bank end, which can make full use of precious solar energy resources and guarantee the safe and reliable operation of the battery bank.
| Model | MPPT solar charger | MSC-420-50 | MSC-420-100 | MSC-420-200 | |
|---|---|---|---|---|---|
| Match solar panel parameters | Solar panels power | 23100Wp | 46200Wp | 92400Wp | — |
| Max. Power voltage range Vmp | DC550V~DC800V | ||||
| Open circuit Voltage Voc | < DC1000V | ||||
| Low voltage protection Vlow-pv | > Battery Low voltage protection (Settable) | ||||
| Charging characteristics | Applicable battery type | Sealed lead-acid battery, colloidal lead-acid battery, open lead-acid battery (customizable for other types) | |||
| Battery rated voltage | DC420V | ||||
| Start charging Vstart-pv | Vpv > Vbat | ||||
| Floating voltage | DC508V (Settable) | ||||
| Battery Low voltage protection | Settable | ||||
| Rated charging current | — | 50A | 100A | 200A | |
| Over current protection | — | 60A | 120A | 240A | |
| Charging mode | Three stages: constant current (fast charging), constant pressure, floating charging | ||||
| Display / communication | Display mode | Touch screen | |||
| Communication protocol | Modbus RTU / Modbus TCP | ||||
| Communication mode | RS485 / USB / Wifi / GPRS / RJ45 / CAN (optional) | ||||
| App cloud monitoring | Support Wifi / GPRS / Ethernet | ||||
| Other features | Protection function | Input and output overvoltage and undervoltage protection, anti reverse connection protection, etc | |||
| MPPT efficiency | ≥99.5% | ||||
| Cooling Mode | Fan | ||||
| Working environment temperature | -20°C ~ +50°C | ||||
| Storage temperature | -40°C ~ +75°C | ||||
| IP protection level | IP20 (customizable outdoor IP65) | ||||
