| Type | NB48-10KSZ | NB96-10KSZ | NB120-10KSZ | NB240-10KSZ | |
|---|---|---|---|---|---|
| DC input | Input rated voltage | 48 VDC | 96 VDC | 120 VDC | 240 VDC |
| Input rated current | 231 A | 116 A | 93 A | 46 A | |
| Input DC voltage range | 40-62 VDC | 80-124 VDC | 100-155 VDC | 200-310 VDC | |
| AC Input (AC bypass) | Allow input voltage range | 220 VAC / 380 VAC / 400 VAC ± 15% | |||
| Input rated current | 28A / 15A / 14.5A | ||||
| Bypass transfer time | ≤40ms (Can be customized ≤4ms version) | ||||
| AC output | Output rated power | 10KW | |||
| Output rated voltage and frequency | 220 VAC / 380 VAC / 400 VAC, 50Hz / 60Hz | ||||
| Output rated current | 28A / 15A / 14.5A | ||||
| Output voltage accuracy | 220 VAC / 380 VAC / 400 VAC ± 1% | ||||
| Output frequency accuracy | 50Hz / 60Hz ± 0.05% | ||||
| Wave Form | Pure sine wave (Isolation transformer) | ||||
| THD. | ≤3% (Linear load) | ||||
| Power factor (PF) | 1 | ||||
| Overload capacity | 120%, 5 minutes; 200%, 3 seconds | ||||
| Crest factor (CF) | 3:1 | ||||
| Inverter efficiency | >94% | ||||
| Working Environment | Dielectric strength | 1500VAC, 1 minute | |||
| Noise (1m) | ≤50dB | ||||
| Ambient temperature | -20°C ~ +60°C | ||||
| Humidity | 0~90%, No condensation | ||||
| Altitude | <2000m (Higher than 2000m rated power should be reduced) | ||||
| Protection function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection | ||||
| Pure Sine Wave | Yes | ||||
| Equipped with copper transformer | Yes | ||||
| Communication mode | RS485, Wifi, GPRS, Ethernet (Modbus RTU protocol) | ||||
| Solar Charger | Optional, available | ||||
| AC Charger | Optional, available | ||||
| Generator Port | Optional, available | ||||
| Size (mm) | 450×830×1100 mm | ||||
| Weight (kg) | 180 kg | ||||
| Type | NB48-20KSZ | NB96-20KSZ | NB120-20KSZ | NB240-20KSZ | |
|---|---|---|---|---|---|
| DC input | Input rated voltage | 48 VDC | 96 VDC | 120 VDC | 240 VDC |
| Input rated current | 463 A | 231 A | 185 A | 93 A | |
| Input DC voltage range | 40-62 VDC | 80-124 VDC | 100-155 VDC | 200-310 VDC | |
| AC input (AC Bypass) | Allow input voltage range | 220 VAC / 380 VAC / 400 VAC ± 15% | |||
| Input rated current | 55.5A / 30A / 29A | ||||
| Bypass transfer time | ≤100ms (Can be customized ≤4ms version) | ||||
| AC output | Output rated power | 20KW | |||
| Output rated voltage and frequency | 220 VAC / 380 VAC / 400 VAC, 50Hz / 60Hz | ||||
| Output rated current | 55.5A / 30A / 29A | ||||
| Output voltage accuracy | 220 VAC / 380 VAC / 400 VAC ± 2% | ||||
| Output frequency accuracy | 50Hz / 60Hz ± 0.05% | ||||
| Waveform distortion (THD) | ≤3% (Linear load) | ||||
| Dynamic response time (Load 0↔100%) | 2ms | ||||
| Power factor (PF) | 1 | ||||
| Overload capacity | 120%, 5 minutes; 200%, 3 seconds | ||||
| Crest factor (CF) | 3:1 | ||||
| Inverter efficiency | 94% | ||||
| Working Environment | Dielectric strength | 1500VAC, 1 minute | |||
| Noise (1m) | ≤50dB | ||||
| Ambient temperature | -20°C ~ +60°C | ||||
| Humidity | 0~90%, No condensation | ||||
| Altitude | <6000m (Higher than 2000m rated power should be reduced) | ||||
| Protection function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection | ||||
| Pure Sine Wave | Yes | ||||
| Equipped with copper transformer | Yes | ||||
| Communication mode | RS485, Wifi, GPRS, Ethernet (Modbus RTU protocol) | ||||
| Solar Charger | Optional, available | ||||
| AC Charger | Optional, available | ||||
| Generator Port | Optional, available | ||||
| Size (mm) | 520×1160×1350 mm | ||||
| Weight (kg) | 280 kg | ||||
| Type | NB120-30KSZ | NB240-30KSZ | NB380-30KSZ | |
|---|---|---|---|---|
| DC input | Input rated voltage | 120 VDC | 240 VDC | 380 VDC |
| Input rated current | 278 A | 139 A | 88 A | |
| Input DC voltage range | 100-155 VDC | 200-310 VDC | 320-496 VDC | |
| AC input (AC Bypass) | Allow input voltage range | 220 VAC / 380 VAC / 400 VAC ± 15% | ||
| Input rated current | 83A / 45.5A / 43.5 A | |||
| Bypass transfer time | ≤100ms (Can be customized ≤4ms version) | |||
| AC output | Output rated power | 30KW | ||
| Output rated voltage and frequency | 220 VAC / 380 VAC / 400 VAC, 50Hz / 60Hz | |||
| Output rated current | 83A / 45.5A / 43.5 A | |||
| Output voltage accuracy | 220 VAC / 380 VAC / 400 VAC ± 1% | |||
| Output frequency accuracy | 50Hz / 60Hz ± 0.05% | |||
| Waveform distortion (THD) | ≤3% (Linear load) | |||
| Dynamic response time (Load 0↔100%) | 2ms | |||
| Power factor (PF) | 1 | |||
| Overload capacity | 120%, 5 minutes; 200%, 3 seconds | |||
| Crest factor (CF) | 3:1 | |||
| Inverter efficiency | 94% | |||
| Working Environment | Dielectric strength | 1500VAC, 1 minute | ||
| Noise (1m) | ≤50dB | |||
| Ambient temperature | -20°C ~ +60°C | |||
| Humidity | 0~90%, No condensation | |||
| Altitude | <2000m (Higher than 2000m rated power should be reduced) | |||
| Protection function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection | |||
| Pure Sine Wave | Yes | |||
| Equipped with copper transformer | Yes | |||
| Communication mode | RS485, Wifi, GPRS, Ethernet (Modbus RTU protocol) | |||
| Solar Charger | Optional, available | |||
| AC Charger | Optional, available | |||
| Generator Port | Optional, available | |||
| Size (mm) | 660*1300*1600 mm | |||
| Weight (kg) | 360 kg | |||
| Type | NB220-40KSZ | NB240-40KSZ | NB380-40KSZ | |
|---|---|---|---|---|
| DC input | Input rated voltage | 220 VDC | 240 VDC | 380 VDC |
| Input rated current | 202 A | 185 A | 117 A | |
| Input DC voltage range | 180-279 VDC | 200-310 VDC | 320-496 VDC | |
| AC input (AC Bypass) | Allow input voltage range | 220 VAC / 380 VAC / 400 VAC ± 15% | ||
| Input rated current | 111.2A / 60.8A / 58A | |||
| Bypass transfer time | ≤100ms (Can be customized ≤4ms version) | |||
| AC output | Output rated power | 40KW | ||
| Output rated voltage and frequency | 220 VAC / 380 VAC / 400 VAC, 50Hz / 60Hz | |||
| Output rated current | 111.2A / 60.8A / 58A | |||
| Output voltage accuracy | 220 VAC / 380 VAC / 400 VAC ± 1% | |||
| Output frequency accuracy | 50Hz / 60Hz ± 0.05% | |||
| Waveform distortion (THD) | ≤3% (Linear load) | |||
| Dynamic response time (Load 0↔100%) | 2ms | |||
| Power factor (PF) | 1 | |||
| Overload capacity | 120%, 5 minutes; 200%, 3 seconds | |||
| Crest factor (CF) | 3:1 | |||
| Inverter efficiency | 94% | |||
| Working Environment | Dielectric strength | 1500VAC, 1 minute | ||
| Noise (1m) | ≤50dB | |||
| Ambient temperature | -20°C ~ +60°C | |||
| Humidity | 0~90%, No condensation | |||
| Altitude | <6000m (Higher than 2000m rated power should be reduced) | |||
| Pure Sine Wave | Yes | |||
| Equipped with copper transformer | Yes | |||
| Communication mode | RS485, Wifi, GPRS, Ethernet (Modbus RTU protocol) | |||
| AC Charger | Optional | |||
| Solar Charger | Optional | |||
| Generator port | Optional | |||
| Protection function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection | |||
| Size (mm) | 760*1400*1600 mm | |||
| Weight (kg) | 550 kg | |||
| Type | NB480-50KSZ | NB380-50KSZ | |
|---|---|---|---|
| DC input | Input rated voltage | 480 VDC | 380 VDC |
| Input rated current | 115 A | 146 A | |
| Input DC voltage range | 400-620 VDC | 320-496 VDC | |
| AC input (AC Bypass) | Allow input voltage range | 220 VAC / 380 VAC / 400 VAC ± 15% | |
| Input rated current | 139A / 76A / 72.5A | ||
| Bypass transfer time | ≤100ms (Can be customized ≤4ms version) | ||
| AC output | Output rated power | 50KW | |
| Output rated voltage and frequency | 220 VAC / 380 VAC / 400 VAC, 50Hz / 60Hz | ||
| Output rated current | 139A / 76A / 72.5A | ||
| Output voltage accuracy | 220 VAC / 380 VAC / 400 VAC ± 1% | ||
| Output frequency accuracy | 50Hz / 60Hz ± 0.05% | ||
| Waveform distortion (THD) (Linear load) | ≤3% | ||
| Dynamic response time (Load 0↔100%) | 2ms | ||
| Power factor (PF) | 1 | ||
| Overload capacity | 120%, 5 minutes; 200%, 3 seconds | ||
| Crest factor (CF) | 3:1 | ||
| Inverter efficiency | 94% | ||
| Working Environment | Dielectric strength | 1500VAC, 1 minute | |
| Noise (1m) | ≤50dB | ||
| Ambient temperature | -20°C ~ +60°C | ||
| Humidity | 0~90%, No condensation | ||
| Altitude | <2000m (Higher than 2000m rated power should be reduced) | ||
| Pure Sine Wave | Yes | ||
| Equipped with copper transformer | Yes | ||
| Communication mode | RS485, Wifi, GPRS, Ethernet (Modbus RTU protocol) | ||
| AC Charger | Optional | ||
| Solar Charger | Optional | ||
| Generator port | Optional | ||
| Protection function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection | ||
| Size (mm) | 660*1300*1600 mm | ||
| Weight (kg) | 450 kg | ||
The inverters feature Mitsubishi IGBT modules as the key power components and American Atmel microprocessors as the digital controllers to ensure high performance and reliable operation.
The standard bypass transfer time is ≤40ms for the 10KW model and ≤100ms for models from 20KW to 50KW. A faster version of ≤4ms can be customized upon request.
The inverters support RS485, Wifi, GPRS, and Ethernet communication interfaces utilizing the standard Modbus RTU protocol for remote system management and monitoring.
No, the AC charger, solar charger, and generator ports are optional, customizable functions that can be added according to specific application demands.
The systems provide extensive protection mechanisms including DC input reverse polarity protection, DC input under-voltage protection, AC output overload protection, AC output short-circuit protection, and over-temperature (thermal) protection.
Yes, these inverters deliver a pure sine wave output equipped with a built-in copper isolation transformer, keeping total harmonic distortion (THD) under 3% for linear loads.
