| Type | NB48-10KSZ | NB96-10KSZ | NB120-10KSZ | NB240-10KSZ | |
|---|---|---|---|---|---|
| DC Input | Input rated voltage | 48 VDC | 96 VDC | 120 VDC | 240 VDC |
| Input rated current | 231 A | 116 A | 93 A | 46 A | |
| Input DC voltage range | 40-62 VDC | 80-124 VDC | 100-155 VDC | 200-310 VDC | |
| AC Input (Bypass) | Allow input voltage range | 220 VAC / 380 VAC / 400 VAC ± 15% | |||
| Input rated current | 28A / 15A / 14.5A | ||||
| Bypass transfer time | ≤ 40ms (Can be customized ≤ 4ms) | ||||
| AC Output | Output rated power | 10KW | |||
| Output voltage & Frequency | 220 VAC / 380 VAC / 400 VAC, 50Hz / 60Hz | ||||
| Output rated current | 28A / 15A / 14.5A | ||||
| Output voltage accuracy | 220 VAC / 380 VAC / 400 VAC ± 1% | ||||
| Output frequency accuracy | 50Hz / 60Hz ± 0.05% | ||||
| Wave Form | Pure sine wave (Isolation transformer) | ||||
| THD | ≤ 3% (Linear load) | ||||
| Power factor (PF) | 1 | ||||
| Overload capacity | 120% for 5 minutes, 200% for 3 seconds | ||||
| Crest factor (CF) | 3:1 | ||||
| Inverter efficiency | > 94% | ||||
| Working Environment | Dielectric strength | 1500VAC, 1 minute | |||
| Noise (1m) | ≤ 50dB | ||||
| Ambient temperature | -20℃ ~ +60℃ | ||||
| Humidity | 0~90%, No condensation | ||||
| Altitude | < 2000m (derating required above 2000m) | ||||
| Protection Function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection | ||||
| Pure Sine Wave / Copper Transformer | Yes / Yes | ||||
| Communication Mode | RS485, Wifi, GPRS, Ethernet (Modbus RTU protocol) | ||||
| Solar / AC Charger / Generator Port | Optional, available | ||||
| Size (mm) / Weight (kg) | 450 × 830 × 1100 mm / 180 kg | ||||
| Type | NB48-20KSZ | NB96-20KSZ | NB120-20KSZ | NB240-20KSZ | |
|---|---|---|---|---|---|
| DC Input | Input rated voltage | 48 VDC | 96 VDC | 120 VDC | 240 VDC |
| Input rated current | 463 A | 231 A | 185 A | 93 A | |
| Input DC voltage range | 40-62 VDC | 80-124 VDC | 100-155 VDC | 200-310 VDC | |
| AC Input (Bypass) | Allow input voltage range | 220 VAC / 380 VAC / 400 VAC ± 15% | |||
| Input rated current | 55.5A / 30A / 29A | ||||
| Bypass transfer time | ≤ 100ms (Can be customized ≤ 4ms) | ||||
| AC Output | Output rated power | 20KW | |||
| Output voltage & Frequency | 220 VAC / 380 VAC / 400 VAC, 50Hz / 60Hz | ||||
| Output rated current | 55.5A / 30A / 29A | ||||
| Output voltage accuracy | 220 VAC / 380 VAC / 400 VAC ± 2% | ||||
| Output frequency accuracy | 50Hz / 60Hz ± 0.05% | ||||
| Wave Form | Pure sine wave (Isolation transformer) | ||||
| THD | ≤ 3% (Linear load) | ||||
| Dynamic response time | 2ms (Load 0←→100%) | ||||
| Power factor (PF) / Crest factor (CF) | 1 / 3:1 | ||||
| Overload capacity | 120% for 5 minutes, 200% for 3 seconds | ||||
| Inverter efficiency | 94% | ||||
| Working Environment | Dielectric strength / Noise (1m) | 1500VAC, 1 minute / ≤ 50dB | |||
| Ambient temperature | -20℃ ~ +60℃ | ||||
| Humidity | 0~90%, No condensation | ||||
| Altitude | < 6000m (derating required above 2000m) | ||||
| Protection Function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection | ||||
| Pure Sine Wave / Copper Transformer | Yes / Yes | ||||
| Communication Mode | RS485, Wifi, GPRS, Ethernet (Modbus RTU protocol) | ||||
| Solar / AC Charger / Generator Port | Optional, available | ||||
| Size (mm) / Weight (kg) | 520 × 1160 × 1350 mm / 280 kg | ||||
| Type | NB120-30KSZ | NB240-30KSZ | NB380-30KSZ | |
|---|---|---|---|---|
| DC Input | Input rated voltage | 120 VDC | 240 VDC | 380 VDC |
| Input rated current | 278 A | 139 A | 88 A | |
| Input DC voltage range | 100-155 VDC | 200-310 VDC | 320-496 VDC | |
| AC Input (Bypass) | Allow input voltage range | 220 VAC / 380 VAC / 400 VAC ± 15% | ||
| Input rated current | 83A / 45.5A / 43.5 A | |||
| Bypass transfer time | ≤ 100ms (Can be customized ≤ 4ms) | |||
| AC Output | Output rated power | 30KW | ||
| Output voltage & Frequency | 220 VAC / 380 VAC / 400 VAC, 50Hz / 60Hz | |||
| Output rated current | 83A / 45.5A / 43.5 A | |||
| Output voltage accuracy | 220 VAC / 380 VAC / 400 VAC ± 1% | |||
| Output frequency accuracy | 50Hz / 60Hz ± 0.05% | |||
| Wave Form / THD | Pure sine wave (Isolation transformer) / ≤ 3% | |||
| Dynamic response time | 2ms (Load 0←→100%) | |||
| Power factor (PF) / Crest factor (CF) | 1 / 3:1 | |||
| Overload capacity | 120% for 5 minutes, 200% for 3 seconds | |||
| Inverter efficiency | 94% | |||
| Working Environment | Dielectric strength / Noise (1m) | 1500VAC, 1 minute / ≤ 50dB | ||
| Ambient temperature | -20℃ ~ +60℃ | |||
| Humidity | 0~90%, No condensation | |||
| Altitude | < 2000m (derating required above 2000m) | |||
| Protection Function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection | |||
| Pure Sine Wave / Copper Transformer | Yes / Yes | |||
| Communication Mode | RS485, Wifi, GPRS, Ethernet (Modbus RTU protocol) | |||
| Solar / AC Charger / Generator Port | Optional, available | |||
| Size (mm) / Weight (kg) | 660 * 1300 * 1600 mm / 360 kg | |||
| Type | NB220-40KSZ | NB240-40KSZ | NB380-40KSZ | |
|---|---|---|---|---|
| DC Input | Input rated voltage | 220 VDC | 240 VDC | 380 VDC |
| Input rated current | 202 A | 185 A | 117 A | |
| Input DC voltage range | 180-279 VDC | 200-310 VDC | 320-496 VDC | |
| AC Input (Bypass) | Allow input voltage range | 220 VAC / 380 VAC / 400 VAC ± 15% | ||
| Input rated current | 111.2A / 60.8A / 58A | |||
| Bypass transfer time | ≤ 100ms (Can be customized ≤ 4ms) | |||
| AC Output | Output rated power | 40KW | ||
| Output voltage & Frequency | 220 VAC / 380 VAC / 400 VAC, 50Hz / 60Hz | |||
| Output rated current | 111.2A / 60.8A / 58A | |||
| Output voltage accuracy | 220 VAC / 380 VAC / 400 VAC ± 1% | |||
| Output frequency accuracy | 50Hz / 60Hz ± 0.05% | |||
| Wave Form / THD | Pure sine wave (Isolation transformer) / ≤ 3% | |||
| Dynamic response time | 2ms (Load 0←→100%) | |||
| Power factor (PF) / Crest factor (CF) | 1 / 3:1 | |||
| Overload capacity | 120% for 5 minutes, 200% for 3 seconds | |||
| Inverter efficiency | 94% | |||
| Working Environment | Dielectric strength / Noise (1m) | 1500VAC, 1 minute / ≤ 50dB | ||
| Ambient temperature | -20℃ ~ +60℃ | |||
| Humidity | 0~90%, No condensation | |||
| Altitude | < 6000m (derating required above 2000m) | |||
| Protection Function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection | |||
| Pure Sine Wave / Copper Transformer | Yes / Yes | |||
| Communication Mode | RS485, Wifi, GPRS, Ethernet (Modbus RTU protocol) | |||
| AC / Solar Charger / Generator Port | Optional | |||
| Size (mm) / Weight (kg) | 760 * 1400 * 1600 mm / 550 kg | |||
| Type | NB480-50KSZ | NB380-50KSZ | |
|---|---|---|---|
| DC Input | Input rated voltage | 480 VDC | 380 VDC |
| Input rated current | 115 A | 146 A | |
| Input DC voltage range | 400-620 VDC | 320-496 VDC | |
| AC Input (Bypass) | Allow input voltage range | 220 VAC / 380 VAC / 400 VAC ± 15% | |
| Input rated current | 139A / 76A / 72.5A | ||
| Bypass transfer time | ≤ 100ms (Can be customized ≤ 4ms) | ||
| AC Output | Output rated power | 50KW | |
| Output voltage & Frequency | 220 VAC / 380 VAC / 400 VAC, 50Hz / 60Hz | ||
| Output rated current | 139A / 76A / 72.5A | ||
| Output voltage accuracy | 220 VAC / 380 VAC / 400 VAC ± 1% | ||
| Output frequency accuracy | 50Hz / 60Hz ± 0.05% | ||
| Wave Form / THD | Pure sine wave (Isolation transformer) / ≤ 3% | ||
| Dynamic response time | 2ms (Load 0←→100%) | ||
| Power factor (PF) / Crest factor (CF) | 1 / 3:1 | ||
| Overload capacity | 120% for 5 minutes, 200% for 3 seconds | ||
| Inverter efficiency | 94% | ||
| Working Environment | Dielectric strength / Noise (1m) | 1500VAC, 1 minute / ≤ 50dB | |
| Ambient temperature | -20℃ ~ +60℃ | ||
| Humidity | 0~90%, No condensation | ||
| Altitude | < 2000m (derating required above 2000m) | ||
| Protection Function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection | ||
| Pure Sine Wave / Copper Transformer | Yes / Yes | ||
| Communication Mode | RS485, Wifi, GPRS, Ethernet (Modbus RTU protocol) | ||
| AC / Solar Charger / Generator Port | Optional | ||
| Size (mm) / Weight (kg) | 660 * 1300 * 1600 mm / 450 kg | ||
These inverters utilize advanced IGBT components from Mitsubishi company for heavy-duty power output, controlled by highly efficient microprocessors from ATMEL company to ensure precise execution and stable controller operation.
The standard bypass transfer time is less than or equal to 40ms for the 10KW model, and less than or equal to 100ms for larger models (20KW to 50KW). A customized high-speed version with a transfer time of less than or equal to 4ms is also available.
Yes, all models in this series generate a pure sine wave output and come equipped with an integrated copper isolation transformer. This setup provides superior inductive load handling capabilities and protects connected equipment from harmonic distortions.
The inverters feature robust communication configurations. They natively support RS485, Wifi, GPRS, and Ethernet transmission modes running under the standard Modbus RTU protocol, allowing easy integration into third-party monitoring platforms.
The device features full-scale multi-level protections, including DC input reverse polarity protection, input under-voltage protection, output overload protection, output short-circuit protection, and over-temperature (thermal) protection.
These options are modular and highly customizable. They can be added optionally during ordering to match specific requirements for hybrid solar, AC utility grid, or backup generator systems.
