Product parameter
Technical parameters of three-phase off-grid inverter 10KW
| Type |
NB48-10KSZ |
NB96-10KSZ |
NB120-10KSZ |
NB240-10KSZ |
| DC Input |
| Input rated voltage |
48 VDC |
96 VDC |
120 VDC |
240 VDC |
| Input rated current |
231 A |
116 A |
93 A |
46 A |
| Input DC voltage range |
40-62 VDC |
80-124 VDC |
100-155 VDC |
200-310 VDC |
| AC Input (AC bypass) |
| Allow input voltage range |
220 VAC / 380 VAC / 400 VAC ± 15% VAC |
| Input rated current |
28A / 15A / 14.5A |
| Bypass transfer time |
≤40ms (Can be customized ≤ 4ms version) |
| AC Output |
| Output rated power |
10KW |
| Output rated voltage and frequency |
220 VAC / 380 VAC / 400 VAC, 50Hz / 60Hz |
| Output rated current |
28A / 15A / 14.5A |
| Output voltage accuracy |
220 VAC / 380 VAC / 400 VAC ± 1% |
| Output frequency accuracy |
50Hz / 60Hz ± 0.05% |
| Wave Form |
Pure sine wave (Isolation transformer) |
| THD. |
≤3% (Linear load) |
| Power factor (PF) |
1 |
| Overload capacity |
120%, 5 minutes / 200%, 3 seconds |
| Crest factor (CF) |
3:1 |
| Inverter efficiency |
>94% |
| Working Environment |
| Dielectric strength |
1500VAC, 1 minute |
| Noise (1m) |
≤50dB |
| Ambient temperature |
-20℃ ~ +60℃ |
| Humidity |
0~90%, No condensation |
| Altitude |
<2000m (Higher than 2000m rated power should be reduced) |
| Functionality & Physics |
| Protection function |
Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection |
| Pure Sine Wave |
Yes |
| Equipped with copper transformer |
Yes |
| Communication mode |
RS485, Wifi, GPRS, Ethernet (Modbus RTU protocol) |
| Solar Charger |
Optional, available |
| AC Charger |
Optional, available |
| Generator Port |
Optional, available |
| Size(mm) |
450×830×1100 mm |
| Weight(kg) |
180 kg |
Technical parameters of three-phase off-grid inverter 20KW
| Type |
NB48-20KSZ |
NB96-20KSZ |
NB120-20KSZ |
NB240-20KSZ |
| DC Input |
| Input rated voltage |
48 VDC |
96 VDC |
120 VDC |
240 VDC |
| Input rated current |
463 A |
231 A |
185 A |
93 A |
| Input DC voltage range |
40-62 VDC |
80-124 VDC |
100-155 VDC |
200-310 VDC |
| AC Input (AC Bypass) |
| Allow input voltage range |
220 VAC / 380 VAC / 400 VAC ± 15% VAC |
| Input rated current |
55.5A / 30A / 29A |
| Bypass transfer time |
≤100ms (Can be customized ≤4ms version) |
| AC Output |
| Output rated power |
20KW |
| Output rated voltage and frequency |
220 VAC / 380 VAC / 400 VAC, 50Hz / 60Hz |
| Output rated current |
55.5A / 30A / 29A |
| Output voltage accuracy |
220 VAC / 380 VAC / 400 VAC ± 2% |
| Output frequency accuracy |
50Hz / 60Hz ± 0.05% |
| Waveform distortion (THD). |
≤3% (Linear load) |
| Dynamic response time (Load 0↔100%) |
2ms |
| Power factor (PF) |
1 |
| Overload capacity |
120%, 5 minutes / 200%, 3 seconds |
| Crest factor (CF) |
3:1 |
| Inverter efficiency |
94% |
| Working Environment |
| Dielectric strength |
1500VAC, 1minute |
| Noise (1m) |
≤50dB |
| Ambient temperature |
-20℃ ~ +60℃ |
| Humidity |
0~90%, No condensation |
| Altitude |
<6000m (Higher than 2000m rated power should be reduced) |
| Functionality & Physics |
| Protection function |
Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection |
| Pure Sine Wave |
Yes |
| Equipped with copper transformer |
Yes |
| Communication mode |
RS485, Wifi, GPRS, Ethernet (Modbus RTU protocol) |
| Solar Charger |
Optional, available |
| AC Charger |
Optional, available |
| Generator Port |
Optional, available |
| Size(mm) |
520×1160×1350 mm |
| Weight(kg) |
280 kg |
Technical parameters of three-phase off-grid inverter 30KW
| Type |
NB120-30KSZ |
NB240-30KSZ |
NB380-30KSZ |
| DC Input |
| Input rated voltage |
120 VDC |
240 VDC |
380 VDC |
| Input rated current |
278A |
139 A |
88 A |
| Input DC voltage range |
100-155 VDC |
200-310 VDC |
320-496 VDC |
| AC Input (AC Bypass) |
| Allow input voltage range |
220 VAC / 380 VAC / 400 VAC ± 15% VAC |
| Input rated current |
83A / 45.5A / 43.5 A |
| Bypass transfer time |
≤100ms (Can be customized ≤4ms version) |
| AC Output |
| Output rated power |
30KW |
| Output rated voltage and frequency |
220 VAC / 380 VAC / 400 VAC, 50Hz / 60Hz |
| Output rated current |
83A / 45.5A / 43.5 A |
| Output voltage accuracy |
220 VAC / 380 VAC / 400 VAC ± 1% |
| Output frequency accuracy |
50Hz / 60Hz ± 0.05% |
| Waveform distortion (THD). |
≤3% (Linear load) |
| Dynamic response time (Load 0↔100%) |
2ms |
| Power factor (PF) |
1 |
| Overload capacity |
120%, 5 minutes / 200%, 3 seconds |
| Crest factor (CF) |
3:1 |
| Inverter efficiency |
94% |
| Working Environment |
| Dielectric strength |
1500VAC, 1minute |
| Noise (1m) |
≤50dB |
| Ambient temperature |
-20℃ ~ +60℃ |
| Humidity |
0~90%, No condensation |
| Altitude |
<2000m (Higher than 2000m rated power should be reduced) |
| Functionality & Physics |
| Protection function |
Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection |
| Pure Sine Wave |
Yes |
| Equipped with copper transformer |
Yes |
| Communication mode |
RS485, Wifi, GPRS, Ethernet (Modbus RTU protocol) |
| Solar Charger |
Optional, available |
| AC Charger |
Optional, available |
| Generator Port |
Optional, available |
| Size(mm) |
660*1300*1600mm |
| Weight(kg) |
360kg |
Technical parameters of three-phase off-grid inverter 40KW
| Type |
NB220-40KSZ |
NB240-40KSZ |
NB380-40KSZ |
| DC Input |
| Input rated voltage |
220Vdc |
240Vdc |
380 VDC |
| Input rated current |
202 A |
185 A |
117 A |
| Input DC voltage range |
180-279 VDC |
200-310 VDC |
320-496 VDC |
| AC Input (AC Bypass) |
| Allow input voltage range |
220 VAC / 380 VAC / 400 VAC ± 15% VAC |
| Input rated current |
111.2A / 60.8A / 58A |
| Bypass transfer time |
≤100ms (Can be customized ≤4ms version) |
| AC Output |
| Output rated power |
40KW |
| Output rated voltage and frequency |
220 VAC / 380 VAC / 400 VAC, 50Hz / 60Hz |
| Output rated current |
111.2A / 60.8A / 58A |
| Output voltage accuracy |
220 VAC / 380 VAC / 400 VAC ± 1% |
| Output frequency accuracy |
50Hz / 60Hz ± 0.05% |
| Waveform distortion (THD). |
≤3% (Linear load) |
| Dynamic response time (Load 0↔100%) |
2ms |
| Power factor (PF) |
1 |
| Overload capacity |
120%, 5 minutes / 200%, 3 seconds |
| Crest factor (CF) |
3:1 |
| Inverter efficiency |
94% |
| Working Environment |
| Dielectric strength |
1500VAC, 1minute |
| Noise (1m) |
≤50dB |
| Ambient temperature |
-20℃ ~ +60℃ |
| Humidity |
0~90%, No condensation |
| Altitude |
<6000m (Higher than 2000m rated power should be reduced) |
| Functionality & Physics |
| Pure Sine Wave |
Yes |
| Equipped with copper transformer |
Yes |
| Communication mode |
RS485, Wifi, GPRS, Ethernet (Modbus RTU protocol) |
| AC Charger |
Optional |
| Solar Charger |
Optional |
| Generator port |
Optional |
| Protection function |
Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection |
| Size(mm) |
760*1400*1600mm |
| Weight(kg) |
550kg |
Technical parameters of three-phase off-grid inverter 50KW
| Type |
NB480-50KSZ |
NB380-50KSZ |
| DC Input |
| Input rated voltage |
480 VDC |
380 VDC |
| Input rated current |
115 A |
146 A |
| Input DC voltage range |
400-620 VDC |
320-496 VDC |
| AC Input (AC Bypass) |
| Allow input voltage range |
220 VAC / 380 VAC / 400 VAC ± 15% VAC |
| Input rated current |
139A / 76A / 72.5A |
| Bypass transfer time |
≤100ms (Can be customized ≤4ms version) |
| AC Output |
| Output rated power |
50KW |
| Output rated voltage and frequency |
220 VAC / 380 VAC / 400 VAC, 50Hz / 60Hz |
| Output rated current |
139A / 76A / 72.5A |
| Output voltage accuracy |
220 VAC / 380 VAC / 400 VAC ± 1% |
| Output frequency accuracy |
50Hz / 60Hz ± 0.05% |
| Waveform distortion (THD) (Linear load) |
≤3% |
| Dynamic response time (Load 0↔100%) |
2ms |
| Power factor (PF) |
1 |
| Overload capacity |
120%, 5 minutes / 200%, 3 seconds |
| Crest factor (CF) |
3:1 |
| Inverter efficiency |
94% |
| Working Environment |
| Dielectric strength |
1500VAC, 1minute |
| Noise (1m) |
≤50dB |
| Ambient temperature |
-20℃ ~ +60℃ |
| Humidity |
0~90%, No condensation |
| Altitude |
<2000m (Higher than 2000m rated power should be reduced) |
| Functionality & Physics |
| Pure Sine Wave |
Yes |
| Equipped with copper transformer |
Yes |
| Communication mode |
RS485, Wifi, GPRS, Ethernet (Modbus RTU protocol) |
| AC Charger |
Optional |
| Solar Charger |
Optional |
| Generator port |
Optional |
| Protection function |
Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection |
| Size(mm) |
660*1300*1600mm |
| Weight(kg) |
450kg |
Frequently Asked Questions
What is the advantage of using a Mitsubishi IGBT in this inverter?
The Mitsubishi Insulated Gate Bipolar Transistor (IGBT) provides superior power component performance. It ensures high thermal efficiency, faster switching speeds, and robust reliability under heavy load conditions compared to standard power components.
Which communication modes are supported?
The inverter supports RS485, Wifi, GPRS, and Ethernet protocols. It runs on the Modbus RTU protocol, allowing for easy remote data monitoring and management.
Can I customize the bypass transfer time?
Yes. The standard bypass transfer time is ≤40ms for the 10KW model and ≤100ms for larger models. However, we offer customized options with a transfer time of ≤4ms to protect highly sensitive electrical equipment.
Does the inverter come equipped with built-in protections?
Yes, the inverter features comprehensive built-in protections, including DC input reverse polarity protection, under-voltage protection, AC output overload protection, short-circuit protection, and thermal/over-temperature protection.
Are solar and AC chargers integrated or optional?
Both solar charge controllers and AC battery chargers are offered as optional, modular integrations. You can choose to add them depending on your specific system requirements and setup configuration.
How does the altitude affect the inverter's rated power?
The inverter operates at 100% capacity up to an altitude of 2000m. For installation sites higher than 2000m, the rated power output must be derated due to thinner air and reduced cooling efficiency.
