| Model | 1KW 2KW 3KW 5KW 10KW 15KW 20KW 30KW 50KW 100KW 200KW 300KW |
| Rated speed(r/min) | 100r/min 150r/min 200r/min 300r/min 450r/min |
| Rated power(KW) | 50KW |
| Working Voltage | DC48-550V/AC110-480V |
| Rated current(A) | 138, 100 A |
| Start-up wind speed(m/s) | 3m/s |
| Rated wind speed(m/s) | 10-12m/s |
| Safe wind speed(m/s) | 35-45m/s |
| No of blades | 3 pieces |
| Material of blades | FRP strengthened |
| Generator | 3 phases PM generator |
| Braking system | Electromagnetic Brake + Manual Brake |
The wind turbine has a low start-up wind speed requirement of only 3m/s, which allows the system to begin power generation even in light breeze conditions.
It utilizes a highly efficient 3-phase Permanent Magnet (PM) generator. This design maximizes energy conversion efficiency and ensures reliable, long-term performance.
The system features a dual braking configuration, combining an Electromagnetic Brake and a Manual Brake. It is designed to safely withstand maximum wind speeds between 35m/s and 45m/s.
The blades are constructed from Fiber Reinforced Plastic (FRP strengthened), providing high tensile strength, weather resistance, and lightweight operation for optimal efficiency.
The product lineup supports rated power configurations ranging from 1KW up to 300KW, with working voltages compatible with DC48-550V and AC110-480V standards.
