Our permanent magnet generators are widely used in wind power, hydropower, ocean energy, ships, diesel generators, aviation, hand-crank generators, and other industrial fields.
| Parameter | Value / Detail |
|---|---|
| Rated Power | 0.5-5500KW |
| Rated Rotate Speed | 20-3000rpm |
| Rated Voltage | 48-1140Vac |
| Frequency | 50/60HZ |
| Number of Poles | 24 |
| Generator Type | 3 phase AC Synchronous Generator |
| Magnet Type | NdFeB |
| Winding Method | Y |
| Magnet temperature level | Max.120℃ |
| Winding Temperature Level | Max.180℃ |
| Efficiency | >95% |
| Insulate Grade | H |
| Insulating resistance | 100Mohm Min(500Vdc) |
| Classification of degrees | IP54 |
| Generator shell material | Cast Iron |
| Winding material | 100% Copper |
| Shaft material | Steel |
| Iron Core | Cold rolled silicon steel sheet |
| Bearing brand | SKF |
| Cooling Method | Fan Cooling |
| Weight (N.W /G.W ) | 132kg /152kg |
| Installation | Horizontal |
| RATED POWER | RATED SPEED | RATED VOLTAGE | FREQUENCY |
|---|---|---|---|
| 0.5KW | 20rpm~400rpm | 12V~220Vac | 10Hz~60Hz |
| 1KW | 20rpm~600rpm | 12V~220Vac | 10Hz~60Hz |
| 2KW | 20rpm~1000rpm | 12V~400Vac | 10Hz~60Hz |
| 3KW | 20rpm~1500rpm | 48V~690Vac | 10Hz~60Hz |
| 5KW | 20rpm~1500rpm | 48V~690Vac | 10Hz~60Hz |
| 10KW | 20rpm~1500rpm | 120V~690Vac | 10Hz~60Hz |
| 15KW | 20rpm~3000rpm | 120V~690Vac | 10Hz~60Hz |
| 20KW | 20rpm~3000rpm | 120V~690Vac | 10Hz~60Hz |
| 25KW | 20rpm~3000rpm | 120V~1140Vac | 10Hz~60Hz |
| 30KW | 20rpm~3000rpm | 120V~1140Vac | 10Hz~60Hz |
| 50KW | 20rpm~3000rpm | 220V~1140Vac | 10Hz~60Hz |
| 80KW | 20rpm~3000rpm | 220V~1140Vac | 10Hz~60Hz |
| 100KW | 20rpm~3000rpm | 220V~1140Vac | 10Hz~60Hz |
| 150KW | 20rpm~3000rpm | 380V~1140Vac | 10Hz~60Hz |
| 200KW | 20rpm~3000rpm | 380V~1140Vac | 10Hz~60Hz |
| 250KW | 20rpm~3000rpm | 380V~1140Vac | 10Hz~60Hz |
| 300KW | 20rpm~3000rpm | 380V~1140Vac | 10Hz~60Hz |
| 500KW | 20rpm~3000rpm | 380V~1140Vac | 10Hz~60Hz |
| 700KW | 20rpm~3000rpm | 690V~1140Vac | 10Hz~60Hz |
| 800KW | 20rpm~3000rpm | 690V~1140Vac | 10Hz~60Hz |
| 1MW | 200rpm~3000rpm | 690V~1140Vac | 10Hz~60Hz |
| 2MW | 200rpm~3000rpm | 690V~1140Vac | 10Hz~60Hz |
| 3MW | 200rpm~3000rpm | 690V~1140Vac | 10Hz~60Hz |
| 4MW | 600rpm~3000rpm | 690V~1140Vac | 10Hz~60Hz |
| 5MW | 600rpm~3000rpm | 690V~1140Vac | 10Hz~60Hz |
Our permanent magnet generators are widely used in wind power, hydropower, ocean energy, marine propulsion, diesel generator sets, aviation systems, and hand-crank emergency generators.
Yes, they are highly suitable for direct-drive wind turbines. Since they do not require a gearbox, they operate highly efficiently even at low rotor speeds with high torque.
Yes, we provide customization services based on individual requirements. We can adjust the Rated Power (0.5-5500KW), Rotate Speed (20-3000rpm), Voltage (12V-1140Vac), and Frequency (50Hz/60Hz).
Our generators feature rare earth NdFeB permanent magnets, boasting a long lifetime exceeding 20 years. They are maintenance-free and can run continuously at high speeds 24 hours a day, 7 days a week.
We use 100% pure copper for the windings, cast iron for the shell, steel for the shaft, and cold-rolled silicon steel sheet for the iron core. Bearings are sourced from the premium SKF brand.
They feature Class H insulation, IP54 ingress protection rating, and winding temperature resistance of up to 180°C. This ensures stable and safe operations in demanding environments.
